Homebridge SmartRent

The most comprehensive SmartRent Homebridge integration to date, Homebridge Verified. Control your SmartRent devices with Apple Home: supporting 6 device types w/ real-time updates, battery monitoring, and advanced status reporting.

Supported Devices

All devices report online/offline status via the StatusActive characteristic.

Architecture

graph TD
    Home["🏠 Apple Home"]

    subgraph Homebridge
        platform["<b>SmartRentPlatform</b><br>DynamicPlatformPlugin"]
        accessories["<b>Accessories</b><br>Lock · Thermostat · Leak<br>Motion · Switch · Dimmer"]
    end

    subgraph SmartRent Cloud
        rest["<b>REST API</b><br>control.smartrent.com/api/v3"]
        ws["<b>WebSocket</b><br>Phoenix protocol<br>real-time state updates"]
        auth["<b>OAuth + TOTP</b><br>authentication/sessions"]
    end

    Home <-->|"HomeKit"| accessories
    platform --> accessories
    platform -->|"device discovery<br>state commands"| rest
    platform <-->|"heartbeat 30s<br>attribute events"| ws
    platform -->|"email/password<br>+ optional 2FA"| auth
    auth --> rest
    auth --> ws

Features

• Real-time updates — WebSocket connection with Phoenix heartbeat for instant state changes across all devices
• 6 device types — Locks, thermostats, leak sensors, motion sensors, switches, and dimmers
• Accurate HVAC status — Uses the thermostat's actual operating state (heating/cooling/idle), not just the target mode
• Lock jam detection — Detects and reports lock jams via SmartRent notification events
• Battery monitoring — Battery level and low-battery alerts for locks and leak sensors
• Device online/offline status — Reports device reachability for all device types
• Two-factor authentication — Full TOTP support for secured SmartRent accounts
• Auto-lock — Configurable timer to automatically re-lock after unlocking
• Per-device toggles — Enable or disable any device type independently via config

Installation

Install Homebridge, add it to Apple Home, then install and configure Homebridge SmartRent.

Recommended

1. Open the Homebridge UI.

2. Open the Plugins tab, search for homebridge-smartrent, and install the plugin.

3. Log in to SmartRent through the settings panel, and optionally set your unit name.

Manual

1. Install the plugin using NPM:

   npm i -g @jackietreeh0rn/homebridge-smartrent


2. Configure the SmartRent platform in ~/.homebridge/config.json as shown in config.example.json.

3. Start Homebridge:

   homebridge -D


Configuration

Property	Type	Default	Description
email	string	required	SmartRent account email
password	string	required	SmartRent account password
tfaSecret	string		32-character TOTP seed for two-factor authentication
unitName	string		Unit name — only needed if you have multiple units. Find it in the SmartRent app under the More tab.
enableLocks	boolean	true	Enable lock accessories
enableThermostats	boolean	true	Enable thermostat accessories
enableLeakSensors	boolean	true	Enable leak sensor accessories
enableMotionSensors	boolean	true	Enable motion sensor accessories
enableSwitches	boolean	true	Enable switch accessories
enableSwitchMultiLevels	boolean	true	Enable dimmer/multilevel switch accessories
enableAutoLock	boolean	false	Automatically re-lock after unlocking
autoLockDelayInMinutes	integer	5	Minutes to wait before auto-locking
excludeDevices	array		List of SmartRent device IDs to exclude from HomeKit. Device IDs are shown in logs at startup.
lowBatteryThreshold	integer	20	Battery percentage at or below which devices report low battery status (5–50)
temperatureUnit	string	fahrenheit	Temperature display unit for thermostats (fahrenheit or celsius)
verboseLogging	boolean	false	Enable verbose debug logging for troubleshooting

Development

Prerequisites

• Node.js 18.20.4+, 20.18.0+, 22.10.0+, or 24.0.0+
• Homebridge 1.8.0+ or 2.0.0-beta+

Setup

npm install
npm run build
npm link

Watch Mode

Automatically recompiles and restarts Homebridge on source changes:

npm run watch

This runs a local Homebridge instance in debug mode using the config at ./test/hbConfig/. Stop any other Homebridge instances first to avoid port conflicts. The watch behavior can be adjusted in nodemon.json.

Linting & Formatting

npm run lint        # check for lint errors
npm run lint:fix    # auto-fix lint errors
npm run prettier    # check formatting
npm run format      # auto-fix formatting

Commits must follow Conventional Commits — enforced by pre-commit hooks via commitlint and husky.

Troubleshooting

If you run into issues, check the Homebridge troubleshooting wiki first. If the problem persists, open an issue with as much detail as possible.

Contributing

See CONTRIBUTING.md for guidelines on bug reports, feature requests, and code contributions.

Useful Resources

Read the full write-up: Homebridge SmartRent & Blink — an architectural deep-dive into how both plugins map their respective APIs into HomeKit (HAP service composition, IMMI streaming, OAuth/2FA, motion polling).

• Homebridge Developer Documentation
• Apple HomeKit Documentation

License

GNU GENERAL PUBLIC LICENSE, Version 3

Disclaimer

This project is not endorsed by, directly affiliated with, maintained, authorized, or sponsored by SmartRent Technologies, Inc or Apple Inc. All product and company names are the registered trademarks of their original owners. The use of any trade name or trademark is for identification and reference purposes only and does not imply any association with the trademark holder of their product brand.
