bqplot

2-D plotting library for Project Jupyter

Introduction

bqplot is a 2-D visualization system for Jupyter, based on the constructs of the Grammar of Graphics.

In bqplot, every component of a plot is an interactive widget. This allows the user to integrate visualizations with other Jupyter interactive widgets to create integrated GUIs with a few lines of Python code.

Documentation

You can follow the documentation on https://bqplot.github.io/bqplot

Trying it online

To try out bqplot interactively in your web browser, just click on the Notebook.link link:

Dependencies

This package depends on the following packages:

• ipywidgets (version >=7.0.0, <8.0)
• traitlets (version >=4.3.0, <5.0)
• traittypes (version >=0.2.1, <0.3)
• numpy
• pandas

Installation

Using pip:

pip install bqplot

Using conda:

conda install -c conda-forge bqplot

Note: If you are using JupyterLab <= 2:

jupyter labextension install @jupyter-widgets/jupyterlab-manager bqplot

Examples

Using the pyplot API

Using the Object Model API

Install a previous bqplot version (only for JupyterLab <= 2)

In order to install a previous bqplot version, you need to know which front-end version (JavaScript) matches with the back-end version (Python).

For example, in order to install bqplot 0.11.9, you need the labextension version 0.4.9.

pip install bqplot==0.11.9
jupyter labextension install bqplot@0.4.9

Versions lookup table:

back-end (Python)	front-end (JavaScript)
0.12.14	0.5.14
0.12.13	0.5.13
0.12.12	0.5.12
0.12.11	0.5.11
0.12.10	0.5.10
0.12.9	0.5.9
0.12.8	0.5.8
0.12.7	0.5.7
0.12.6	0.5.6
0.12.4	0.5.4
0.12.3	0.5.3
0.12.2	0.5.2
0.12.1	0.5.1
0.12.0	0.5.0
0.11.9	0.4.9
0.11.8	0.4.8
0.11.7	0.4.7
0.11.6	0.4.6
0.11.5	0.4.5
0.11.4	0.4.5
0.11.3	0.4.4
0.11.2	0.4.3
0.11.1	0.4.1
0.11.0	0.4.0

Development

See our contributing guidelines for the development installation, contributor workflow, and test commands.

License

This software is licensed under the Apache 2.0 license. See the LICENSE file for details.
