Please switch to DragView, for the best support, thank you

DraggablePanel

Download

	allprojects {
		repositories {
			...
			maven { url 'https://jitpack.io' }
		}
	}


    	dependencies {
	        implementation 'com.github.hoanganhtuan95ptit:DraggablePanel:1.2.5'
	}

Using Detail code java

• Xml

        <com.hoanganhtuan95ptit.draggable.DraggablePanel
                android:id="@+id/draggablePanel"
                android:layout_width="match_parent"
                android:layout_height="match_parent"
                app:height_when_max="300dp"
                app:height_when_min="80dp"
                app:margin_bottom_when_min="8dp"
                app:margin_edge_when_min="8dp"
                app:percent_when_middle="0.9"
                app:state="MIN" />

• Listener

        draggablePanel.setDraggableListener(object : DraggablePanel.DraggableListener {
            override fun onChangeState(state: DraggablePanel.State) {
            }

            override fun onChangePercent(percent: Float) {
                alpha.alpha = 1 - percent
            }

        })

• Add frame

        supportFragmentManager.beginTransaction().add(R.id.frameFirst, TopFragment()).commit() // add frame top
        supportFragmentManager.beginTransaction().add(R.id.frameSecond, BottomFragment()).commit() // add frame bottom

• Action

        btnMax.setOnClickListener { draggablePanel.maximize() }// maximize
        btnMin.setOnClickListener { draggablePanel.minimize() }//minimizeo
        btnClose.setOnClickListener { draggablePanel.close() }//close

Custom Detail code java

• Custom

        class DraggableSource @JvmOverloads constructor(
                context: Context, attrs: AttributeSet? = null, defStyleAttr: Int = 0
        ) : DraggablePanel(context, attrs, defStyleAttr) {

            var mWidthWhenMax = 0

            var mWidthWhenMiddle = 0

            var mWidthWhenMin = 0

            init {
                getFrameFirst().addView(inflate(R.layout.layout_top))
                getFrameSecond().addView(inflate(R.layout.layout_bottom))
            }

            override fun initFrame() {
                mWidthWhenMax = width

                mWidthWhenMiddle = (width - mPercentWhenMiddle * mMarginEdgeWhenMin).toInt()

                mWidthWhenMin = mHeightWhenMin * 22 / 9

                super.initFrame()
            }

            override fun refreshFrameFirst() {
                super.refreshFrameFirst()

                val width = if (mCurrentPercent < mPercentWhenMiddle) {
                    (mWidthWhenMax - (mWidthWhenMax - mWidthWhenMiddle) * mCurrentPercent)
                } else {
                    (mWidthWhenMiddle - (mWidthWhenMiddle - mWidthWhenMin) * (mCurrentPercent - mPercentWhenMiddle) / (1 - mPercentWhenMiddle))
                }

                frameTop.reWidth(width.toInt())
            }
        }

• Xml

        <com.hoanganhtuan95ptit.example.custom.DraggableSource
                android:id="@+id/draggablePanel"
                android:layout_width="match_parent"
                android:layout_height="match_parent"
                app:height_when_max="300dp"
                app:height_when_min="80dp"
                app:margin_bottom_when_min="8dp"
                app:margin_edge_when_min="8dp"
                app:percent_when_middle="0.9"
                app:state="MIN" />

• Code

        draggablePanel.setDraggableListener(object : DraggablePanel.DraggableListener {
            override fun onChangeState(state: DraggablePanel.State) {
            }

            override fun onChangePercent(percent: Float) {
                alpha.alpha = 1 - percent
                shadow.alpha = percent
            }

        })

        supportFragmentManager.beginTransaction().add(R.id.frameTop, TopFragment()).commit()
        supportFragmentManager.beginTransaction().add(R.id.frameBottom, BottomFragment()).commit()

        btnMax.setOnClickListener { draggablePanel.maximize() }
        btnMin.setOnClickListener { draggablePanel.minimize() }
        btnClose.setOnClickListener { draggablePanel.close() }
