rstat

[!WARNING] rstat is a demonstration and performance research exercise, not a production desktop application. It is provided as an educational resource on eBPF programming and low-overhead system telemetry.

It has not undergone the QA, compatibility work, hardening, or security testing expected of general desktop software. Known limitations include machine-specific hardware assumptions, a fixed PID/map capacity, unchecked string handling, and incomplete reliability work around multicore probe attachment and cross-system support. Those are examples of the broader point: proper desktop monitoring software needs substantial validation that this project will not receive.

A system monitor that runs inside the kernel. Single-digit microseconds per switch, sub-millisecond per sample. More data than top, iotop, and ps combined.

Most system monitors read /proc -- opening, reading, and closing thousands of files every refresh cycle. top does it. btop does it. They parse ASCII text the kernel formatted from data structures it already had in memory. It is a serialisation round-trip through the filesystem for numbers the kernel could hand you directly.

rstat skips all of that. It injects verified eBPF bytecode into the kernel's scheduler path. When the CPU switches between tasks, the probe reads CPU time, RSS, and IO counters directly from task_struct -- no files, no syscalls, no text parsing. Userspace reads the results from a BPF map in a single batch operation.

The result: a complete system health snapshot (CPU%, memory, memory pressure, swap rate, load, temperature, frequency, GPU, power profile, top-5 processes by CPU/memory/IO with per-process breakdowns) in under 1 millisecond per sample, with each in-kernel probe invocation completing in single-digit microseconds.

How it works

Three BPF tracepoint probes:

• sched_switch -- accounts CPU time, snapshots RSS and IO for the outgoing task
• sched_process_exit -- marks zombies (Z-state), clears seen flag for client handshake
• sched_process_free -- cleans up reaped processes

Runtime guarantees:

• Strict probe health checks at startup (required tracepoints must attach)
• Single-instance lock to avoid partial/competing probe attachments
• Per-thread kernel data aggregated to per-process rows in userspace (by TGID)
• Memory PSI (/proc/pressure/memory) and swap counters (/proc/vmstat) read from persistent file descriptors each sample (no per-tick reopen churn)

Startup /proc scan seeds any pre-existing D/Z processes into the BPF map so they're visible from the first sample.

Userspace daemon (~900 lines of Rust):

• Custom ELF loader (no aya, no libbpf-rs, no tokio, no C build step)
• Batch map reads with pre-allocated arrays
• Hand-written JSON emitter (no serde)
• All buffers pre-allocated and reused

Performance

Stage	Time	Approach
Bash + coreutils	~800 ms	Fork 8-12 subprocesses per sample
Rust + /proc	~700 ms	Direct /proc parsing, one subprocess remained
Optimised /proc	~15 ms	Sysfs, reusable buffers, byte-level parsing
eBPF	<1 ms	BPF probes, batch map reads, hand-written JSON

~200 KB RSS. <0.01% CPU. Two runtime dependencies (libc, goblin).

Building

Rust, by the way. On NixOS, by the way.

Requires Nix with flakes:

nix build

Two-derivation build:

1. rstat-probe -- compiles probe.bpf.c with clang -target bpf -O2 -g
2. rstat -- builds the Rust binary, copies the probe alongside it

The binary requires CAP_SYS_ADMIN (or equivalent, e.g. NixOS security.wrappers) for bpf() and perf_event_open().

Waybar integration

"custom/sysmon": {
    "exec": "rstat",
    "return-type": "json",
    "restart-interval": 0,
    "on-click": "kill -RTMIN $(pgrep rstat)",
    "on-click-middle": "kill -RTMIN+1 $(pgrep rstat)"
}

Controls

Default interval is 500ms.

Left-click cycles the update interval: 500ms → 250 → 100 → 2000 → 1000 → 500ms. The 100ms floor is the fastest Waybar can reliably render with GTK -- below that, pipe backpressure throttles output regardless of sample speed.

kill -RTMIN $(pgrep rstat)

--ludicrous bypasses the Waybar limit for terminal use. Sets the sample interval to 16ms (~60 fps). Pipe to a terminal or TUI that can keep up:

sudo rstat --ludicrous

Kernel mode is enabled by default.

Middle-click toggles kernel inclusion for all relevant sections (CPU, Memory, IO). The tooltip footer shows the current mode as Kernel included or Kernel excluded.

kill -RTMIN+1 $(pgrep rstat)

Benchmarking

sudo ./target/release/rstat --bench 200

Runs 200 sample iterations and prints p50/p95/p99 latencies.

Profiling BPF overhead

sudo rstat --profile 10

Measures per-invocation probe latency over 10 seconds and prints a log2 histogram. The probe self-times using bpf_ktime_get_ns() on every context switch.

Writeup

The full story of how this went from an 800ms shell script to sub-millisecond eBPF:
